AGITO MagTrax enables productions to follow a guaranteed path precisely every time using a magnetic strip that is discreetly laid or embedded and hidden in your set. The magnetic strip can be positioned and repositioned quickly and easily between takes.
AGITO MagTrax includes built-in front and rear safety bumpers for sensitive collision detection and automatic e-stop. All bumper edges are receptive to light touch, providing additional security when working in confined environments or remote operation.
Each bumper has an embedded status light bar programmed to display all or some LEDs in diverse colours according to the current situation and state. Setup mode with strength & marker detection, Studio operation mode with pulsing orange while moving and Driving mode with white & red.
A magnetic strip can be installed under a carpet or embedded within a set for concealed operation while not sacrificing the guaranteed trajectory of AGITO. The sensor bar detects the magnetic strip under most non-metallic surfaces keeping the track completely invisible.
Magnetic markers are used to define safety end-stops instructing the AGITO to stop at the end of the path automatically. The braking behaviour can be pre-determined ahead of time, removing the worry of braking near the end of the strip.
AGITO MagTrax can break away and re-join (BAR) current and other magnetic strips within the environment by switching between MagTrax and free-roaming mode. BAR allows multiple paths to be defined, providing maximum flexibility and creativity.
MagTrax enhances the existing Sports drive-ends enabling customers to follow a magnetic strip laid on a surface, underneath a carpet or embedded within a set. The magnetic strip can be arranged in various creative ways beyond what you can do with a regular track.
AGITO MagTrax enables a combination of curves and can move seamlessly from one strip to another. The AGITO will autonomously follow each path while freeing up camera movement control for single operator capability.
BUNDLES
New systems can be purchased pre-configured with MagTrax with new bundles, AGITO MagTrax Essential and AGITO MagTrax Elevated.
MagTrax can also be added to existing SPORTS systems using the SPORTS-MagTrax upgrade pack or to existing TRAX systems using the TRAX-MagTrax upgrade pack.
- AGITO Core & Master Controller
- AGITO Sports Drive-Ends
- Dolly Wheels
- AGITO V-Con Pro Vertical Stabiliser
- MagTrax Kit
- AGITO Core & Master Controller
- AGITO Sports Drive-Ends
- Dolly Wheels
- AGITO Tower
- MagTrax Kit
SPECIFICATIONS
Key features
- Magnetic strip guided system for discreet tracked applications using either laid or set-embedded paths.
- The same manoeuvrability as free roaming with guaranteed repeatable movement.
- Bumper, collision detection and automatic E-stop.
- Configurable front and rear lighting system for setup and production state awareness.
- Automatic E-Stop on loss of track.
| Min. Speed | 0.35ft/s (0.1m/s) |
|---|---|
| Max. Speed | 12mph (19km/h)* |
| Min. Track Corner Radius | 1.2m (4ft)** |
| Max Track Length | As long as you want! |
|---|---|
| Sensor Length | 505mm (20″) |
| Number of paths | As many as you want! |
**Speed dependent
